CONSUMER UNIT & RCBO Model : PREMIER Series

Attribute:

Share


CONSUMER UNIT & RCBO Model :  PREMIER Series

 Model ; Number of slots

Size of Main Circuit Breaker (In)

4

32A,50A,63A

6

32A,50A,63A

8

50A,63A

10

50A,63A

12

50A,63A

Properties

           This is a new product from Safe-T-Cut which is designed in a modern shape and bright color to suit with modern home style. The transparency cover designed to protect the unit from dust and insect but yet allow user to see the functional of the inside circuit. In case of services this cover also can remain open for your comfortable with glow in the dark tab for visibility purpose. The standard visible icon to show the operating position is also stick inside the body for an easy operating. The body is made from Electro-Galvanized sheet steel and sprayed with Epoxy Powder which is high resistance to corrosion and durable.

           Bus bar made of pure copper with nickel plate and ground bar is also included.

        Consumer Unit & RCBO Premier have all the function of protecting electric leakage, electric shock (through human body) , Short circuit and over loaded. This model is suit with home building and office use.

         Consumer Unit & RCBO Premier has 4,6,8 and 10 port to choose with 1 pole sub-breaker IEC60898 standard and 7 level of loaded to select which are 6,10,16,20,25,32 and 45 A. This product is certified by Thai Industrial Standard 1436-2540



ราคา : กรุณาโทรติดต่อสอบถามทางร้าน

เบอร์โทรศัพท์ : 02-428-9754, 02-428-9765

เบอร์มือถือ : 097-461-6656

Line ID : @MKKS2539
